The Asetek Invicta Clutch System is compatible with all Asetek Invicta and Forte pedals, both S-Series and the regular fixed baseplate versions.
With the Invicta S-Series / Forte S-Series pedals, you can adjust the spacing between the clutch pedal and brake pedal.
Conversely, with the regular fixed base plate pedal versions of the Invicta / Forte pedals, the clutch pedal is in a fixed position relative to the brake pedal.
INTUITIVE ATTACHMENT TO BRAKE & THROTTLE
With the acknowledgement that not all race cars are equipped with a manual clutch, Asetek SimSports® supplies the Invicta Clutch as a separate add-on product to make sure that all racers’ preferences are considered.
The clutch slides directly on to the Invicta Pedals Brake & Throttle and Forte Pedals Brake & Throttle by tightening two screws and a small electrical connector. With this, you are ready to turn your racing simulator from automatic to manual clutch. In just a few steps, you are ready to drive.
Asetek SimSports Invicta Pedals are for Competitive Gamers and Racing Enthusiasts who want the ultimate immersive sim racing experience. The Invicta sim racing pedals feature a proper clutch bite point with a realistic rebound to give you the best and most realistic racing experience of driving on a real circuit with sim pedals.
GENERAL TECH & DIMENSIONS
Exquisite, radical, and minimalistic industrial Danish design (Registered Community Design No. 009148265-0001/0002/0003)
16-bit magnetic wireless hall CPS (Clutch Position Sensor) with no mechanical wear and zero maintenance
Die-cast aluminium zero play pedal arm with integrated long durability ball bearings and bronze bushing at the clevis rotation point
Pedal arm designed for 200 kg of force and a burst pressure of up to 700 kg!
Four mechanical pedal curve settings
Spring load adjustment
Attaches to Invicta Pedals Brake & Throttle and Forte Pedals Brake & Throttle
Both Invicta and Forte pedal face plates are included
Adjustable pedal stop
Adjustable travel settings
Made in Denmark
Sustainable manufacturing with 100% on-site re-use of waste material
Die-cast high-quality pedal base with integrated heel rest and RGB LED that can be adjusted, dimmed or turned completely off in the RaceHub™ software
The clutch can be calibrated through the RaceHub software
Clutch upper and lower deadzone, as well as bite point, can be set through the
RaceHub software
All adjustable mechanical features are by default coloured orange
If purchasing the Invicta™ Clutch separately, you will have to use hex keys supplied when purchasing the Invicta Pedals Brake & Throttle or the Forte Pedals Brake & Throttle, or purchase them separately at your local hardware store
Dimensions: 406 mm x 115 mm x 271 mm (depth x width x height)
Weight: 1.6kg
